SR301은
대용량의 유량을 사용할 때 방열핀을 통과하여
몸체에 서리가
끼는 것을 방지할 수 있습니다.
▶ FEATURES
• Machined body and housing
cap
• 2”
gauges
• Stem type seat
mechanism
• Self reseating relief
valve (not designed to protect
downstream
apparatus)
▶ MATERIALSOFCONSTRUCTION
Body
..........................................................Aluminum
Diaphragm
.....................Fabric reinforced neoprene
Housing cap
..............................................Aluminum
Inlet Filter
.......................................................Bronze
▶ SPECIFICATIONS
Maximum
inlet ............................................1500 psig
Outlet
range (psig)
SR 310............................................10-150
psig
Maximum
outlet ranges (SCFH)
SR
310..............................................200 SCFH
Outlet
connection..................................5/8-18” (F) RH
Optional
1/4” NPT (M) connection available.
Order
part no. 0950-0163 if required
Weight
|
